LNG Bunkering and Fuel Gas Supply System Simulator
Wärtsilä LNG bunkering and fuel gas supply system simulator

Raise the level of your training and safety onboard with our hyper realistic 3D LNG bunkering and supply systems simulator.

Contact us

Wärtsilä LNG bunkering and fuel gas supply system simulator

As the move towards LNG fuel gathers pace in the marine industry, it is essential that crew members are thoroughly and expertly trained on handling the related systems. Wärtsilä Voyage’s training solution uses an uber-realistic 3D LNG Bunkering simulator with automated training scenarios to raise training levels on LNG bunkering and supply systems and onboard safety levels.

Key benefits

  • Suitable for the IGF code training: Certification for basic and advanced training in line with STCW requirements.
  • Prepare for emergencies: Alarms, shutdowns, leakages, disconnection of hoses, overfilling and overpressure in tanks.
  • Run scenarios and practice independently: Perfect for systems familiarisation, refresher training, self-training
  • Easy to set up, scale: Different configurations depending on your needs: from lap-top set up to classroom with full-mission configuration.
  • Customisation: It is also possible to order a customised model corresponding to your system, enabling type-specific training, case studies, and prediction of system behaviour.

Key features

  • Familiarisation with LNG bunkering and fuel gas supply system
  • System layout and flow diagrams
  • Taking fuel tanks in and out of service
  • LNG bunkering procedures
  • LNG fuel storage and securing
  • LNG fuel delivery to the engines
  • Control System, Automation, Alarm and Safety System
  • Watchkeeping and Troubleshooting
  • Emergency Response

How it works

Future of renewable energy with LNG



The journey towards a 100% renewable energy future is different for every continent, every country, and every city—each has its own individual path. Wärtsilä Voyage can help create your optimal path towards a 100% renewable energy future.

Additional information

Compliance

  • The LNG Bunkering simulator is qualified for usage in basic and advanced IGF code training according to STCW 2010 Manila amendments Code for the normal operating conditions and emergency response.
  • The LNG bunkering simulator is also certified by ClassNK to comply with STCW 2010 Manila amendments Code A/ Table A-V/3-1 and A-V/3-2.
  • Table A-V/3-1 Specification of a minimum standard of competence in basic training for ships subject to the IGF Code
  • Table A-V/3-2 Specification of a minimum standard of competence of advanced training for ships subject to the IGF Code.

Purchase option

Wärtsilä LNG Bunkering simulator is available for one-off sale and as an annual subscription, depending on customer preferences. A wide range of service and warranty options are available for the customer of TechSim simulators, including delivery and installation services, software and equipment upgrades, remote support, information, and training services.

Training Content

IGF Code Basic and Advanced courseware



This courseware is the teaching aid, helping to conduct the instructor-led training and the student-led self-preparation of the trainees for the Basic and Advanced Training for the seafarers on ships subject to IGF Code.

Training includes lectures and simulator-based training and requires the usage of “Wartsila TechSim LNG Bunkering and Fuel Gas System Supply Simulator.”



This courseware was developed in cooperation with Aboa Mare (Finland).



IGF Code Basic

IGF code Advanced

STCW Table A-V/3-1 IMO Model Course 7.13

STCW Table A-V/3-2 IMO Model Course 7.14

  • Rules and legislations
  •  Fuel gases
  • Handling LNG
  • Fuel Storage Onboard
  • Safety and protection systems
  • Operating Principles
  • Health hazards
  • Bunkering LNG
  • Gas physics
  • Bunkering system
  • LNG Storage System
  • LNG Fuelled Engines
  • Safety Systems
  • Bunkering LNG



Detailed physical modelling, including the following effects:



  • LNG thermodynamics and phase transition in tanks, piping, heat exchangers
  • LNG composition corresponds to the selected source of bunkering
  • LNG weathering due to boil-off process in the tank
  • Dilution of fuel gas with nitrogen used to purge the system
  • Methane number and Lower Heating Value affecting the engine operation
